Contract Details

• Contract Sign Date: June 2015
• Contract Amount: 305,223,910.00 SAR

Scope of Work

The project is divided into three main parts, each addressing different aspects of the construction and installation process.

Part 1: 380kV Underground Cables

• Work Involved: Construction of two 380kV underground cable circuits (CKT 01) with two cables per phase.
• Route Length: 8 km

Tasks

• Design, supply, and installation of cables
• Construction, testing, and pre-commissioning activities

Part 2: Transition Gantries

• Work Involved: Construction of three transition gantries to integrate the underground cables into the existing network infrastructure.

Part 3: Tunnels and Mechanical Building

• Work Involved:
  • Construction of deep and square tunnels, including shafts for cable routing
  • Installation of two micro tunnels
  • Construction of a mechanical building to house essential systems and equipment
